Making a large Lathe Fixed Steady from scrap ..
« on: August 23, 2012, 12:47:51 PM »
I have some 5" SS pipe that  needed to be cut .... pref square !!

So I needed a large fixed steady for the lathe ... an old rear brake disc and an old lorry part for the base. Both parts are cast steel which is very nice to machine.


Cleaned the brake disc up a little to get rid of the rust ... it's a rough quick finish, will tidy later..

http://i401.photobucket.com/albums/pp92/thebodger/Astra/BlackBox%20Lives%20On/IMG_8730.jpgMaking a large Lathe Fixed Steady from scrap ..

Need to make some locating slots for these three fingers from my normal sized steady

http://i401.photobucket.com/albums/pp92/thebodger/Astra/BlackBox%20Lives%20On/IMG_8731.jpgMaking a large Lathe Fixed Steady from scrap ..

Used the milling machine and bolted the disc to my rotary table to index at 120 degrees

http://i401.photobucket.com/albums/pp92/thebodger/Astra/BlackBox%20Lives%20On/IMG_8732.jpgMaking a large Lathe Fixed Steady from scrap ..

http://i401.photobucket.com/albums/pp92/thebodger/Astra/BlackBox%20Lives%20On/IMG_8734.jpgMaking a large Lathe Fixed Steady from scrap ..

http://i401.photobucket.com/albums/pp92/thebodger/Astra/BlackBox%20Lives%20On/IMG_8735.jpgMaking a large Lathe Fixed Steady from scrap ..

Cut one flat edge

http://i401.photobucket.com/albums/pp92/thebodger/Astra/BlackBox%20Lives%20On/IMG_8737.jpgMaking a large Lathe Fixed Steady from scrap ..

Starting the base from a part from an old lorry ..

http://i401.photobucket.com/albums/pp92/thebodger/Astra/BlackBox%20Lives%20On/IMG_8739.jpgMaking a large Lathe Fixed Steady from scrap ..

http://i401.photobucket.com/albums/pp92/thebodger/Astra/BlackBox%20Lives%20On/IMG_8740.jpgMaking a large Lathe Fixed Steady from scrap ..

Which fits here

http://i401.photobucket.com/albums/pp92/thebodger/Astra/BlackBox%20Lives%20On/IMG_8741.jpgMaking a large Lathe Fixed Steady from scrap ..

Cut a slot in the base to fit the brake disc

http://i401.photobucket.com/albums/pp92/thebodger/Astra/BlackBox%20Lives%20On/IMG_8742.jpgMaking a large Lathe Fixed Steady from scrap ..

Cutting the bell off the disc

http://i401.photobucket.com/albums/pp92/thebodger/Astra/BlackBox%20Lives%20On/IMG_8743.jpgMaking a large Lathe Fixed Steady from scrap ..

And here we are, nearly done ... need to weld the two parts together

http://i401.photobucket.com/albums/pp92/thebodger/Astra/BlackBox%20Lives%20On/IMG_8744.jpgMaking a large Lathe Fixed Steady from scrap ..

A mock set-up to see if it all looks ok

http://i401.photobucket.com/albums/pp92/thebodger/Astra/BlackBox%20Lives%20On/IMG_8746.jpgMaking a large Lathe Fixed Steady from scrap ..
Logged
You will find it a distinct help… if you know and look as if you know what you are doing. (IRS training manual)

Offline dsquire

  • In Memoriam
  • Hero Member
  • *****
  • Posts: 2275
  • Kitchener, Ontario, Canada
Re: Making a large Lathe Fixed Steady from scrap ..
« Reply #1 on: August 23, 2012, 01:00:00 PM »
Darren

Good use for old brake rotors. Too bad a person only needs one or two steadies.  :D :D

Cheers  :beer:

Don

Logged
Good, better, best.
Never let it rest,
'til your good is better,
and your better best

Offline John Rudd

  • Hero Member
  • *****
  • Posts: 2550
Re: Making a large Lathe Fixed Steady from scrap ..
« Reply #2 on: August 23, 2012, 01:53:23 PM »
Ahhh...they say mother is the necessity of invention..... :coffee:

Very innovative Darren..... :bow:

Nice job...
Logged
eccentric millionaire financed by 'er indoors
Location:  Backworth Newcastle

Skype: chippiejnr

Offline saw

  • Hero Member
  • *****
  • Posts: 1003
  • lucky amateur
    • Svenssons AckordsWerkstad
Re: Making a large Lathe Fixed Steady from scrap ..
« Reply #3 on: August 23, 2012, 02:31:24 PM »
Nice work  :clap: :clap:
Logged
_________________________
Greetings / Benni
http://myprojecty.wordpress.com/category/steam-engine/

Offline PekkaNF

  • Hero Member
  • *****
  • Posts: 2523
Re: Making a large Lathe Fixed Steady from scrap ..
« Reply #4 on: August 23, 2012, 02:50:58 PM »
Excellent! I have a rusty brake rotor "ageing" to be reborn as a tramming aid.  Now I probably have to get onother :beer:

Just collecting my braincells together and trying to figure out how to make both sided really parallel. Probably have to mount faceplate first and that will need an adapter....

Pekka
Logged

Offline Stilldrillin

  • Global Moderator
  • Hero Member
  • *****
  • Posts: 4972
  • Staveley, Derbyshire. England.
Re: Making a large Lathe Fixed Steady from scrap ..
« Reply #5 on: August 23, 2012, 03:44:48 PM »
Now....... That's blummin clever! :thumbup:

Well done Darren.  :clap: :clap:

David D
Logged
David.

Still drilling holes... Sometimes, in the right place!

Still modifying bits of metal... Occasionally, making an improvement!
